Servo Wicketer Bag Making Machine
Overview
VEGA Wicketer series machines are designed for high-speed wicket bag making and wicketed bag production with stable bag stacking and superior sealing performance. This is a must-have machine for converters in the modern era of automated packaging at end users and brand owners.
Automatic stacking of bags facilitates high speed production. Possible to make non-wicketed bags also at high speed. These machines offer transition to high scale productivity. Automation of process parameters makes it very easy for operators to deliver high production with less manpower.
Applications
Bread bags, Food packaging bags, Wicketed bags, Hygiene packaging bags, Fresh produce bags, Courier bags, Chicken packaging bags, Kitchen paper roll bags, Shoulder handle bags for diapers.
Why Choose Mamata Wicketers
Must have machine if you supply to automated packaging lines for industry segments of food products, hygiene bags and courier bags. Unmatched level of automation of process parameter set-up helps scale your production compared to conventional side seal machines. If you are looking at higher net yield per day and justifying your investment in building larger diameter rolls on your blown film lines and printing machines, Mamata Wicketer is the perfect choice.
Specifications
| Vega W 600 | Vega W 800 | Vega W 1000 | |
| Types of Webs / Films | HM-HDPE, LDPE, LLDPE, PP, CPP | ||
| Bag Width (Draw Length) (mm) | Max: 410 | Min: 75 | Max: 410 | Min: 75 | Max: 410 | Min: 75 |
| Bag Depth- with 1220 mm (48”) Unwind | Max: 480 | Min: 190 | Max: 610 | Min: 250 | Max: 610 | Min: 250 |
| Bag Depth- with 1520 mm (60”) Unwind | Max: 680 | Min: 250 | Max: 710 | Min: 250 | |
| Gusset Depth | Max: 75 | Min: 25 | Max: 75 | Min: 25 | Max: 75 | Min: 25 |
| Maximum Speed* | Line Speed: 80 mpm | Vacuum Arms: 410 (mm) | Pin Stacker Configuration (No. of Stations): 3+1/4+1 (Optional) | Line Speed: 80 mpm | Vacuum Arms: 410/610 (mm)(Optional) | Pin Stacker Configuration (No. of Stations): 3+1/4+1 (Optional) | Line Speed: 80 mpm | Vacuum Arms: 410/610 (mm)(Optional) | Pin Stacker Configuration (No. of Stations): 3+1/4+1 (Optional) |
