High Speed Flying Knife Bottom Seal Bag Making Machine
Overview
This high-speed Flying Knife Bottom Sealing Machine is designed with advanced flying knife sealing technology to deliver excellent seal quality and superior production output.
Programmable seal distance between two bottom seals provides unique capability to manufacture and set up various bottom sealed bag jobs at the touch of a button.
Applications
Bottom seal bags, Garbage bags, Produce bags, Industrial packaging bags.
Why Choose WIN Series of Mamata Bottom Seal Machines
WIN series bottom seal machines are equipped with efficient and maintenance-friendly flying knife technology that makes it easier for operators to set up jobs and perform quick changeovers. Ability to select how bottom sealing can be done provides unmatched capability to cater to various market segments using a single machine.
Specifications
| Win 600 B | Win 800 B | Win 1100 B | Win 1400 B | |
| Types of Webs / Films | HM-HDPE, LDPE, LLDPE, PP, CPP | |||
| Bag Width (mm) | Max: 600 | Min: 200 | Max: 800 | Min: 150 | Max: 1100 | Min: 200 | Max: 1400 | Min: 250 |
| Draw Length (mm) | Max: 1000 | Min: 100 | Max: 2000/4000 | Min: 100 | Max: 2000/4000 | Min: 100 | Max: 2000/4000 | Min: 100 |
| Maximum Speed* | Bags: 75 cpm | Limiting Line Speed: 80 mpm | Bags: 150 cpm | Limiting Line Speed: 120 mpm | Bags: 140 cpm | Limiting Line Speed: 120 mpm | Bags: 130 cpm | Limiting Line Speed: 120 mpm |
