Advanced Modular Pouch Making Systems
Overview
Top of the line pouch making systems. Advanced modular pouch converting platforms designed for multiple pouch formats including stand-up pouches, flat bottom pouches and specialty pouches.
Independent servo control for each sealing station makes this machine one of the most admired pouch making systems.
Patented OptiSeal® technology allows processing of co-extruded polyethylene films on VEGA PLUS systems. Unique adjustable double cut facility helps produce pouches with notchless round corners preventing sharp edges.
Zone-wise web tension control ensures perfect handling of various film structures making this system unmatched when it comes to processing a wide variety of laminates.
The system allows saving and recalling process parameters resulting in very high setup waste reduction and process optimization. The most important advantage is extremely high consistency and reliability of pouch production at high speed.
Applications
Flat bottom pouches, Stand-up pouches, Specialty pouches, Premium retail packaging.
Why Choose VEGA PLUS Pouch Making Systems
When you need a truly high-end pouch making system that can assure unmatched seal integrity, higher production speeds, absolute sealing control and flexibility to produce multiple pouch formats, VEGA PLUS is the ideal solution.
Specifications
| VegaPlus 410 | VegaPlus 610 | VegaPlus 820 | VegaPlus 1020 | VegaPlus 1220 | |
| Types of Webs / Films | Laminates of Polyester, BOPP, CPP, Co-ex. Films based on Nylon, EVOH, LD/LLD, BOPP, etc. | ||||
| Web Width with 60” Unwinder (mm) | Max: 1520 (60”) | Min: 410 (16”) | ||||
| Web Width with 48” Unwinder (mm) | Max: 1220 (48”) | Min: 410 (16”) | ||||
| Processing Width (PW) (mm) | Max: 410 (16”) | Min: 125 (5”) | Max: 610 (24”)| Min: 210 (8”) | Max: 820 (32”)| Min: 250 (10”) | Max: 1020 (40”)| Min: 300 (12”) | Max: 1220 (48”)| Min: 300 (12”) |
| Maximum Speed cpm | 250 | ||||
